Avionics Safety-Critical Systems

---

Systems engineering is an interdisciplinary field of engineering and engineering management that focuses on how to design, integrate, and manage complex systems over their life cycles. At its core, systems engineering utilizes systems thinking principles to organize this body of knowledge. The individual outcome of such efforts, an engineered system, can be defined as a combination of components that work in synergy to collectively perform a useful function.

Issues such as requirements engineering, reliability, logistics, coordination of different teams, testing and evaluation, maintainability, and many other disciplines, aka "ilities", necessary for successful system design, development, implementation, and ultimate decommission become more difficult when dealing with large or complex projects. Systems engineering deals with work processes, optimization methods, and risk management tools in such projects. It overlaps technical and human-centered disciplines such as industrial engineering, production systems engineering, process systems engineering, mechanical engineering, manufacturing engineering, production engineering, control engineering, software engineering, electrical engineering, cybernetics, aerospace engineering, organizational studies, civil engineering and project management. Systems engineering ensures that all likely aspects of a project or system are considered and integrated into a whole.

The systems engineering process is a discovery process that is quite unlike a manufacturing process. A manufacturing process is focused on repetitive activities that achieve high-

quality outputs with minimum cost and time. The systems engineering process must begin by discovering the real problems that need to be resolved and identifying the most probable or highest-impact failures that can occur. Systems engineering involves finding solutions to these problems.

  Reliability is the probability of a product performing its intended function under specified operating conditions in a manner that meets or exceeds customer expectations

Reliability engineering is a sub-discipline of systems engineering that emphasizes the ability of equipment to function without failure. Reliability is defined as the probability that a product, system, or service will perform its intended function adequately for a specified period of time, OR will operate in a defined environment without failure.

Reliability is closely related to availability, which is typically described as the ability of a component or system to function at a specified moment or interval of time.

The reliability function is theoretically defined as the probability of success. In practice, it is calculated using different techniques, and its value ranges between 0 and 1, where 0 indicates no probability of success while 1 indicates definite success. This probability is estimated from detailed (physics of failure) analysis, previous data sets, or through reliability testing and reliability modeling. Availability, testability, maintainability, and maintenance are often defined as a part of "reliability engineering" in reliability programs. Reliability often plays a key role in the cost-effectiveness of systems.

Reliability engineering deals with the prediction, prevention, and management of high levels of "lifetime" engineering uncertainty and risks of failure. Although stochastic parameters define and affect reliability, reliability is not only achieved by mathematics and statistics. "Nearly all teaching and literature on the subject emphasize these aspects and ignore the reality that the ranges of uncertainty involved largely invalidate quantitative methods for prediction and measurement." For example, it is easy to represent "probability of failure" as a symbol or value in an equation, but it is almost impossible to predict its true magnitude in practice, which is massively multivariate, so having the equation for reliability does not begin to equal having an accurate predictive measurement of reliability.

Reliability engineering relates closely to Quality Engineering, safety engineering, and system safety, in that they use common methods for their analysis and may require input from each other. It can be said that a system must be reliably safe.

Reliability engineering focuses on the costs of failure caused by system downtime, cost of spares, repair equipment, personnel, and cost of warranty claims.

Functional Hazard Assessment (FHA) is a top-down, qualitative analysis that examines potential failure conditions associated with system functions. The primary goal of FHA is to determine how safe a system needs to be by identifying and assessing failure modes and their impact on operations and safety.

FHA is performed early in the system development lifecycle, typically during the System Definition phase, before specific technologies, procedures, or human elements are assigned to functions. It is an iterative process that evolves as the system design progresses.

FHA is essential for several reasons:

1. Ensures System Safety – Identifies hazards and evaluates their impact before implementation.
2. Supports Regulatory Compliance—Helps meet aviation safety standards such as EASA CS-25.1309, FAR Part 25.1309, and SAE ARP4761.
3. Guides System Design – Provides a foundation for functional allocation and helps define necessary safety requirements.
4. Forms the Basis for Further Safety Analysis – Serves as input for Preliminary System Safety Assessments (PSSA) and other risk evaluation methods such as Fault Tree Analysis (FTA) or Markov Analysis (MA).

Failure mode and effects analysis (FMEA; often written with "failure modes" in plural) is the process of reviewing as many components, assemblies, and subsystems as possible to identify potential failure modes in a system and their causes and effects. For each component, the failure modes and their resulting effects on the rest of the system are recorded in a specific FMEA worksheet. There are numerous variations of such worksheets.

A FMEA can be a qualitative analysis, but may be put on a quantitative basis when mathematical failure rate models are combined with a statistical failure mode ratio database. It was one of the first highly structured, systematic techniques for failure analysis. It was developed by reliability engineers in the late 1950s to study problems that might arise from malfunctions of military systems. An FMEA is often the first step of a system reliability study.

A few different types of FMEA analyses exist, such as:

• Functional
• Design
• Process

Sometimes FMEA is extended to FMECA (failure mode, effects, and criticality analysis) to indicate that criticality analysis is performed too.

FMEA is an inductive reasoning (forward logic) single point of failure analysis and is a core task in reliability engineering, safety engineering and quality engineering.

A successful FMEA activity helps identify potential failure modes based on experience with similar products and processes—or based on common physics of failure logic. It is widely used in development and manufacturing industries in various phases of the product life cycle. Effects analysis refers to studying the consequences of those failures on different system levels.

Functional analyses are needed as an input to determine correct failure modes, at all system levels, both for functional FMEA or piece-part (hardware) FMEA. A FMEA is used to structure mitigation for risk reduction based on either failure mode or effect severity reduction, or based on lowering the probability of failure or both. The FMEA is in principle a full inductive (forward logic) analysis, however the failure probability can only be estimated or reduced by understanding the failure mechanism. Hence, FMEA may include information on causes of failure (deductive analysis) to reduce the possibility of occurrence by eliminating identified (root) causes.

Fault tree analysis (FTA) is a type of failure analysis in which an undesired state of a system is examined. This analysis method is mainly used in safety engineering and reliability engineering to understand how systems can fail, to identify the best ways to reduce risk and to determine (or get a feeling for) event rates of a safety accident or a particular system level (functional) failure.

FTA is used in the aerospace,[1] nuclear power, chemical and process,[2][3][4] pharmaceutical,[5] petrochemical and other high-hazard industries; but is also used in fields as diverse as risk factor identification relating to social service system failure. FTA is also used in software engineering for debugging purposes and is closely related to cause-elimination technique used to detect bugs.

In aerospace, the more general term "system failure condition" is used for the "undesired state" / top event of the fault tree. These conditions are classified by the severity of their effects. The most severe conditions require the most extensive fault tree analysis. These system failure conditions and their classification are often previously determined in the functional hazard analysis.
